M50-3150542R,Rectangular Connectors - Headers, Receptacles, Female Sockets,05+05 DIL L/P SMT SKT 1400/RL

Reference Only

M50-3150542R

05+05 DIL L/P SMT SKT 1400/RL

Availability

Standard: 2800 In Stock

Product Details

Manufacturer: Harwin Inc.

SN Part Number: M50-3150542R

Model Part Number: M50-3150542R

Product Category: Rectangular Connectors - Headers, Receptacles, Female Sockets

2800 In Stock

Additional Stock Lead Time: 24 Wks

Quantity

Tech Specifications

Description	Product Attribute
Packaging	Tape & Reel (TR)
Series	Archer M50
Part Status	Active
Connector Type	Receptacle, Bottom or Top Entry
Contact Type	Female Socket
Style	Board to Board or Cable
Number of Positions	10
Number of Positions Loaded	All
Pitch - Mating	0.050" (1.27mm)
Number of Rows	2
Row Spacing - Mating	0.050" (1.27mm)
Mounting Type	Surface Mount
Termination	Solder
Fastening Type	Push-Pull
Contact Finish - Mating	Gold
Contact Finish Thickness - Mating	Flash
Insulation Color	Black
Insulation Height	0.087" (2.20mm)
Contact Length - Post	-
Operating Temperature	-40°C ~ 105°C
Material Flammability Rating	UL94 V-0
Contact Finish - Post	Tin
Mated Stacking Heights	3.2mm, 3.9mm, 4.6mm, 5.3mm, 7.2mm, 8.6mm
Ingress Protection	-
Features	Board Guide, Pick and Place
Current Rating	1A
Voltage Rating	-

Other Information

Packing

Minimum packaging

Minimum order quantity

1400
